Glass Density Measurement Tester Floatation Density Comparator Ceramics Apparent Density Measuring Machine

Brand Name : LONROY

Place of Origin : Guangdong, China

MOQ : 1

Power : 350W

Voltage : 220V

Protection Class : IP56

Dimensions : 530mm × 370mm × 550mm

Weight : 15kg

Temperature Display : 25 + 15℃

Temperature Resolution : 0.001℃

Heating Rate : 0.2 + 0.08℃/minute

Magnetic Stirring Speed : 0 to 1500 rpm

Water Bath Capacity : 5000 mL

Circular Lamp Power : 40W

Magnetic Stirrer Power : 25W

Electric Heater Power : 300W

Test Tube Capacity : 100 mL

Density Range : 1.1 to 3.3 g/cm³

Contact Now

Glass Density Measurement Tester Floatation Density Comparator Ceramics Apparent Density Measuring Machine

Product Description

I. Usage

The LR-A338 float comparison density meter is a density testing instrument designed and manufactured in accordance with the national standard GB/T14901-2008 "Glass Density Measurement - Float Comparison Method". It can be used to measure the density values of glass or other solid materials with no pores within the range of 1.1 to 3.3 g/cm³, and can also be used to measure the apparent density of ceramics or solid materials with known porosity.

II. Measurement method

After reaching the set temperature, the instrument can automatically calculate and display the density value of the standard sample.

III. Instrument composition

The LR-A338 float comparison density meter consists of the following components:

1. A glass water bath with a capacity of 5000 mL.

2. One 40W circular lamp tube.

3. A magnetic stirrer with a speed range of 0 to 1500 r/min, with a power of 25W.

4. One electric heater with a variable resistor, with a power of 300W.

5. Five 100 mL glass test tubes.

6. One dual-probe high-precision digital thermometer.


Glass Density Measurement Tester Floatation Density Comparator Ceramics Apparent Density Measuring Machine

Technical Specification

Temperature Display

25 + 15℃

Temperature Resolution

0.001℃

Heating Rate

Superior to 0.2 + 0.08℃/minute

Magnetic Stirring

Continuous speed adjustment from 0 to 1500 revolutions per minute (rpm)

Water Bath Temperature Difference

Horizontal temperature difference ≤ 0.08℃; Vertical temperature difference ≤ 0.08℃

Power Supply and Power

~220V, 350W

Instrument Size

530mm × 370mm × 550mm (Length × Width × Height)

Instrument Weight

Approximately 15kg
